GRID HYBRID SOLAR INVERTER SCI-SERIES
Equipped with MPPT solar charge controller to maximize and regulateDC power from the solar array for the charging the battery bank.It totally workable on inductive load such as Refrigerator,Air conditioner,Water pump,ect. It’s the ideal inverters for small PV plants, or individually for small houses, solar pump system.
Application:
● Solar pump system.
● Small PV plants
● Home solar system
Features：
● Professional off grid solar system solution, which is a combination of big power inverter and solar controller
● working modes switche automatically- AC Grid bypass mode ,Inverter mode, AC charging mode, solar charging mode
● Pure sine wave output which matches wave form of AC grid no matter it on AC grid mode or Invert Mode; workable on inductive load
● Remote control &RS232 communication port
● Power Saver mode
● Four stages smart charging,Charging current adjusted automatically
● DIP switch optional: Selectable charging voltage for various battery type
● Manual control input&output breakers
● AC Grid priority& battery priority working mode are selectable.
● AC grid mode: AC Bypass supplies load when AC is normal, battery invert AC supplies load when AC is off.
● Battery priority: Battery invert supplies load when battery get full-charged; AC bypass supplies load when battery low and at the meantime battery get charged from solar controller. It transfers back to battery invert mode when battery get full charged. It makes full use of solar energy and saves electricity
● Professional off grid solar system solution, which is a combination of big power inverter and solar controller
● working modes switche automatically- AC Grid bypass mode ,Inverter mode, AC charging mode, solar charging mode
● Pure sine wave output which matches wave form of AC grid no matter it on AC grid mode or Invert Mode; workable on inductive load
● Remote control &RS232 communication port
● Power Saver mode
● Four stages smart charging,Charging current adjusted automatically
● DIP switch optional: Selectable charging voltage for various battery type
● Manual control input&output breakers
● AC Grid priority& battery priority working mode are selectable.
● AC grid mode: AC Bypass supplies load when AC is normal, battery invert AC supplies load when AC is off.
● Battery priority: Battery invert supplies load when battery get full-charged; AC bypass supplies load when battery low and at the meantime battery get charged from solar controller. It transfers back to battery invert mode when battery get full charged. It makes full use of solar energy and saves electricity
